Informations complémentaires
General
| SKU | 2403 |
|---|
Données électriques
| Wattage | 18W per metre |
|---|---|
| Voltage | 12V |
| Power supply | The wattage of the LED strips is given by meter. You need power supply for all LED strips. Depending on the Longueur of the LED strip you need, you can calculate the wattage of the power supply you need. For example, if you have chosen a strip with wattage - 10W per meter and you need 15 meters (3 rolls, 5 meter each) the way to see which power supply you need is multiplying the wattage of the strip per the meters you need. In our example, it will be 10W x 15 meters = 150W. The power supply has to be minimum 150W, it is always good to add around 20% on top of the total wattage in order to make sure the power will be enough. |
Données techniques de l'éclairage
| Light colour | White |
|---|---|
| Temperature de couleur | 6000K |
| Angle du faisceau | 120° |
| Lumens | 2040 lm per metre |
| LED quantity | 204 LEDs per metre |
| Stabilité de la couleur | <6 |
Capacités
| Indice IP | IP20 |
|---|---|
| Cut points | Every 3 LEDs |
| Note | The LED strips come in 5 meter rolls. All the prices are given per one roll (5 meters). |
| Intensité maximale déclarée en candelas (cd) | / |
| Operating Temperature | -25 ~50'C |
| Temps de préchauffage 100% | 0.001 sec |
| Conditions de fonctionnement | Ne convient pas pour une utilisation dans des conditions extrêmes. Les conditions normales de travail sont -20° +45° |
Dimensions et poids
Durée de vie
| Nombre de cycles de commutation | 15000 |
|---|
Certificats et standards
| EEI – Energy Label | Oui |
|---|---|
| CE | Oui |
| RoHS | Oui |
| Energy efficiency class | A |
| EAN Code | 380023062805 |
| Référence | VT-3014 IP20 |
| Garantie | 2 ans |
